Technical Specifications:
STAND: Ergonomic design microscope light & compact body with stable & sturdy C shaped stand, well-contoured modular base, corrosion resistant paint and heat resistant pads. All gear, housing, body are metallic.
VIEWING HEAD: Siedentopf Binocular tube, inclined at 30° rotatable through 360° with interpupillary distance adjustment 48-75 mm and Dioptric adjustment range 378-428 mm on one eyepiece. Anti fungus treated, anti-reflection coated prism.
LCD DIGITAL CAMERA: Display 8" High-resolution(1024x768) Color LCD Touch Screen Built-in Camera 5.0 Megapixel Color Camera 15fps 2592 X 1944.Built-in Software Capture/Measurement App Mechanical Structure LCD Screen 360° horizontal rotatable, 90° vertical rotatable Operating System Android. Output Ports 1 HDMI Port. 1 USB 2.0 Port, 1 Mini USB 2.0 Port Power Supply Input : AC 110V-220V Output : DC 5V Features : Apkinstaller, Browser, Calender, Camera, Chrome, Clock, Downloads, Thousand of Applications Capture Image - Frame Rate - Managing and Browsing Images-Measuring Toolbars
EYEPIECES: Eyepiece WF 10x FN 18 paired with eye guards, anti-fungus treated secured to body to prevent falling off.
NOSEPIECE: Low friction & fully parafocal reversed Quadruple Revolving nosepiece (Ball bearing type).
OBJECTIVES: KEOWABJ series High Definition parafocal DIN Infinity Plan Achromaticlenses, Anti fungus treated objectives:PLAN ACHROMAT 4x/0.10 PLAN ACHROMAT 10x/0.25PLAN ACHROMAT 40x(SL)/0.65PLAN ACHROMAT 100x(SL, Oil)/1.25.
CONDENSER: Moveable & Lockable par centered ABBE Condenser,NA 1.25, with aspheric Lens & slot slider for phase/dark field.
FOCUSING MODULE: Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways. Tension adjustment ring and upper limit stopper.
STAGE: Double layer graduated mechanical rectangular stage size 142 x 133mm cross travel 75 (X) x 50 (Y) mm on ball bearing right side co-axial controls spring clip double specimen holder & fine vernier graduations designed with convenient coaxial adjustment for slide manipulation.
IRIS DIAPHRAGM: special day light blue filter in holder .
ILLUMINATION: Illumination 3W LED Lamp with variable illumination control with LED life upto 10000-30000 hrs.
POWER: Power Input 100-240V 50-60 Hz as per ISO 9001 & CE standards.
STANDARD: Vinyl dust cover, power cord, immersion oil, cleaning solution.
ACCESSORIEWARRANTY: 2 years.
CERTIFICATIONS: ISO 9001:2008, ISO 13485:2012, CE, BIS approved
Technical Specifications:
STAND: Ergonomic design microscope light & compact body with stable & sturdy C shaped stand, well-contoured modular base, corrosion resistant paint and heat resistant pads. All gear, housing, body are metallic.
VIEWING HEAD: Siedentopf Binocular tube, inclined at 30° rotatable through 360° with interpupillary distance adjustment 48-75 mm and Dioptric adjustment range 378-428 mm on one eyepiece. Anti fungus treated, anti-reflection coated prism.
LCD DIGITAL CAMERA: Display 8" High-resolution(1024x768) Color LCD Touch Screen Built-in Camera 5.0 Megapixel Color Camera 15fps 2592 X 1944.Built-in Software Capture/Measurement App Mechanical Structure LCD Screen 360° horizontal rotatable, 90° vertical rotatable Operating System Android. Output Ports 1 HDMI Port. 1 USB 2.0 Port, 1 Mini USB 2.0 Port Power Supply Input : AC 110V-220V Output : DC 5V Features : Apkinstaller, Browser, Calender, Camera, Chrome, Clock, Downloads, Thousand of Applications Capture Image - Frame Rate - Managing and Browsing Images-Measuring Toolbars
EYEPIECES: Eyepiece WF 10x FN 18 paired with eye guards, anti-fungus treated secured to body to prevent falling off.
NOSEPIECE: Low friction & fully parafocal reversed Quadruple Revolving nosepiece (Ball bearing type).
OBJECTIVES: KEOWABJ series High Definition parafocal DIN Infinity Plan Achromaticlenses, Anti fungus treated objectives:PLAN ACHROMAT 4x/0.10 PLAN ACHROMAT 10x/0.25PLAN ACHROMAT 40x(SL)/0.65PLAN ACHROMAT 100x(SL, Oil)/1.25.
CONDENSER: Moveable & Lockable par centered ABBE Condenser,NA 1.25, with aspheric Lens & slot slider for phase/dark field.
FOCUSING MODULE: Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways. Tension adjustment ring and upper limit stopper.
STAGE: Double layer graduated mechanical rectangular stage size 142 x 133mm cross travel 75 (X) x 50 (Y) mm on ball bearing right side co-axial controls spring clip double specimen holder & fine vernier graduations designed with convenient coaxial adjustment for slide manipulation.
IRIS DIAPHRAGM: special day light blue filter in holder .
ILLUMINATION: Illumination 3W LED Lamp with variable illumination control with LED life upto 10000-30000 hrs.
POWER: Power Input 100-240V 50-60 Hz as per ISO 9001 & CE standards.
STANDARD: Vinyl dust cover, power cord, immersion oil, cleaning solution.
ACCESSORIEWARRANTY: 2 years.
CERTIFICATIONS: ISO 9001:2008, ISO 13485:2012, CE, BIS approved
- Regular price
- Rs.30,270.00
GST Invoice included
(Save 18% on business purchases)
Need Quote ?
Get Bulk Order Quotation for your lab or Tender Quotation at special discounts !
Contact our support team at support@labmart.in to get the best quote for your bulk order requirement.
Sales Support - +918920746300
Technical Support- +919667893959
Kindly allow us a time of 2-3 days to properly match all the inquired specs, we will also provide authorization(s) to dealers for particular tenders (on tender basis)
Product Description
Technical Specifications:
STAND: Ergonomic design microscope light & compact body with stable & sturdy C shaped stand, well-contoured modular base, corrosion resistant paint and heat resistant pads. All gear, housing, body are metallic.
VIEWING HEAD: Siedentopf Binocular tube, inclined at 30° rotatable through 360° with interpupillary distance adjustment 48-75 mm and Dioptric adjustment range 378-428 mm on one eyepiece. Anti fungus treated, anti-reflection coated prism.
LCD DIGITAL CAMERA: Display 8" High-resolution(1024x768) Color LCD Touch Screen Built-in Camera 5.0 Megapixel Color Camera 15fps 2592 X 1944.Built-in Software Capture/Measurement App Mechanical Structure LCD Screen 360° horizontal rotatable, 90° vertical rotatable Operating System Android. Output Ports 1 HDMI Port. 1 USB 2.0 Port, 1 Mini USB 2.0 Port Power Supply Input : AC 110V-220V Output : DC 5V Features : Apkinstaller, Browser, Calender, Camera, Chrome, Clock, Downloads, Thousand of Applications Capture Image - Frame Rate - Managing and Browsing Images-Measuring Toolbars
EYEPIECES: Eyepiece WF 10x FN 18 paired with eye guards, anti-fungus treated secured to body to prevent falling off.
NOSEPIECE: Low friction & fully parafocal reversed Quadruple Revolving nosepiece (Ball bearing type).
OBJECTIVES: KEOWABJ series High Definition parafocal DIN Infinity Plan Achromaticlenses, Anti fungus treated objectives:PLAN ACHROMAT 4x/0.10 PLAN ACHROMAT 10x/0.25PLAN ACHROMAT 40x(SL)/0.65PLAN ACHROMAT 100x(SL, Oil)/1.25.
CONDENSER: Moveable & Lockable par centered ABBE Condenser,NA 1.25, with aspheric Lens & slot slider for phase/dark field.
FOCUSING MODULE: Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways. Tension adjustment ring and upper limit stopper.
STAGE: Double layer graduated mechanical rectangular stage size 142 x 133mm cross travel 75 (X) x 50 (Y) mm on ball bearing right side co-axial controls spring clip double specimen holder & fine vernier graduations designed with convenient coaxial adjustment for slide manipulation.
IRIS DIAPHRAGM: special day light blue filter in holder .
ILLUMINATION: Illumination 3W LED Lamp with variable illumination control with LED life upto 10000-30000 hrs.
POWER: Power Input 100-240V 50-60 Hz as per ISO 9001 & CE standards.
STANDARD: Vinyl dust cover, power cord, immersion oil, cleaning solution.
ACCESSORIEWARRANTY: 2 years.
CERTIFICATIONS: ISO 9001:2008, ISO 13485:2012, CE, BIS approved
