Lifting System

Motorized Lift

Height adjustment (mm)

150

Rotation speed (rpm)

20-280

Rotation speed setting

Digital through 4.3” TFT Touch display

Drive

Brushless DC Motor with Microprocessor based Electronic

Speed Control

Heating capacity

1000W

Temp. range heating bath

Ambient to 200°C, 0.1°Cand accuracy Vacuum Controlled Range 0-1000 mbar

Overheat protection bath

Cut-off at 5 °C over set temp.

Bath temperature setting

Digital through 4.3” TFT Touch Display

Material heating bath

Stainless Steel Grade 304

Diameter heating bath (mm)

222 (Inner Dia)

Volume heating bath (L)

5 Ltrs

Integrated vacuum controller

Yes

Timer

Yes

Vacuum program

Yes (0-1000 mbar)

Condensing surface (cm²)

1500

Permissible ambient conditions

5-45°C at 85% humidity

Dimensions with glassware

(610x515x1010) (WxDxH) in mm

Supply voltage

A.C. 180-240 Volts 50/60Hz
