Technical Specifications:

OBSERVATION HEAD: Siedentopf Trinocular head with observation head inclined at 45o.Interpupillary distance from 52mm to 75mm. Diopter adjustment ring on ocular provides correction for eye acuity.

EYEPIECES: Wide Field Eyepieces 10X (PAIRED) FOV 22mm

NOSEPIECE: Quadruple nosepiece revolves on ball bearing with positive indexing. Soft rubber knurled grip on nosepiece.

OBJECTIVE: Long Working Distance Plan Achromatic 10X, Long Working Distance Plan Achromatic 20X, Long Working Distance Plan Achromatic 50X, Long Working Distance Plan Achromatic 100X (SL) Dry.

STAGE:  Mechanical stage with Size 242mm x 200mm, supported on ball bearing guideways and having low positioned co-axial controls for stage movement.

CONDENSER:  Focusable abbe two lens type NA 1.25 condenser with iris diaphragm and swing out filter holder with blue filter.

FOCUSING:  Co-axial focusing control with ball bearing guideways & large knobs, pre focusing lever & tension adjustment ring. The slow motion has 1DIV=0.002mm.

POLARIZING OUTFIT: Analyzer rotatable 360. Polarizer & analyzer can be slided in/out of the optical path.

ILLUMINATION:  Epi-Kohler's illumination. Aperture iris diaphragm and field iris diaphragm 12V/30W halogen lamp or LED lamp with adjustable brightness. Filter wheel fixed in light path with blue, green & yellow filter.

PACKAGING: Complete in plywood cabinet or in STYRO FOAM molded box with day light blue, green filters & dust cover.
