Technical Specifications:

MECHANICAL BODY: Single mold sturdy stand with anti rust materials. Extended base for better stability.

OBSERVATION HEAD:• Siedentopf headwithobservationhead45ºrotatableat360º.• Interpupillary distance from 55mm to75mm.• Phototube for microphotography.• Diopter adjustment ring on ocular provides correction for eye acuity.

EYEPIECES: Wide Field Eyepieces 10X (PAIRED) FOV 18mmn.

NOSEPIECE: Reverse angle quadruple nosepiece revolves on ball bearing with positive indexing. Soft rubber knurled grip on nosepiece.

OBJECTIVES INFINITY CORRECTED: • M  Long Working Distance Plan Achromatic 5X• M Long Working Distance Plan Achromatic 10X• M  Long Working Distance Plan Achromatic 20X• M  Long Working Distance Plan Achromatic 50X (SL)

MECHANICAL STAGE: Mechanical stage Size 180mm x 165mm, supported on ball bearing guideways and having low positioned co-axial controls for stage movement. Hand rests provided on both sides.

FOCUSING: Co-axial focusing control with ball bearing guideways & large knobs, pre focusing lever & tension adjustment ring. The slow motion has 1DIV=0.002mm.

ILLUMINATION:  The Epi-illuminator has 6V/20W halogen lamp, adjustable brightness.

STANDARD ACCESSORIES: Dust Cover, Operating Manual, Blue filter, STYRO FOAM Molded pack
