Features:

• The inner chamber of the hypoxia chamber have volume of 50 / 100 / 150 / 180 liters with Multi Gas Suppy (N2 & CO2).

®

• LuxMe d

Hypoxia Chamber have monitoring system with analog connection port designed to observe

the status of equipment in real time even in the far distance.

®

• LuxMed Hypoxia Chamber have LED display with Individual 2-channel touch button

operating panel.

• Fast CO2, O2, N2, temperature and humidity recovery without overshoot.

®

• LuxMed Hypoxia Chamber have In-line lters remove gas impurities and

contaminants.

®

• LuxMed Hypoxia Chamber have Fast heat-up, fast-recovery, reliable control.

• Digital PID controlled Temperature range should be ambient + 5 °C ~ 60 °C with

accuracy of ±0.1 (37 °C) and resolution of 0.1 °C

®

• LuxMed Hypoxia Chamber have 6 sides direct heating system and the electric heating

wire should be covered on all sides of the chamber to make good uniformity and to provides

fast heat-up & temperature recovery. Gentle air and moisture convection air and moisture in the chamber should be distributed naturally by 6 side heating and the

air circulation fan.

®

• LuxMed Hypoxia Chamber Independently validated overnight cycle ensures complete elimination of all biological contaminants.

• No need to remove IR CO2 sensor.

®

• LuxMed Hypoxia Chamber have 125 °C dry hot air sterilization, conforms to the International standards for dry heat sterilization and proven to effectively

deactivate normally-resistant fungi, bacterial spore and vegetative cells. Non-toxic and non-corrosive sterilization that completes within 12 hours leaving the

chamber cool and dry at the end of the cycle.

• The 3 parts of heating section should be controlled and calibrated individually by 3 individual temperature sensors.

®

• LuxMed Hypoxia Chamber have antimicrobial powder coating to eliminates 99.9% of surface bacteria within 24 hours of exposure.

®

• LuxMed Hypoxia Chamber be dry wall and air jacket system with warm air from heating wire which preserved in space between the chamber and the insulation

layer to helps temperature recover faster and minimize heat loss.

®

• LuxMed Hypoxia Chamber have lower gas consumption and lower heat loss.

• The system insulation should not require regular maintenance.

®

• LuxMed Hypoxia Chamber have dual beam IR CO2 Sensor for fast & precise detection for CO2 gas regardless of temperature and humidity.

• Microprocessor controlled CO2 range should be 0%~20% with Accuracy of ± 0.1 % (5%/37°C), resolution of 0.1% and Inlet pressure range of 0.5 ~ 0.6 bar.

®

• LuxMed Hypoxia Chamber have natural humidification using water tray.

®

• LuxMed Hypoxia Chamber have O2 Range of 0.6 ~ 20% with zirconium dioxide sensor.

®

• LuxMed Hypoxia Chamber have circulation fan to delivers the moisture formed from the water to the entire chamber.

®

• LuxMed Hypoxia Chamber have front door heater & frame heater to prevent condensation in the chamber and on the glass door.

®

• LuxMed Hypoxia Chamber have ULPA/HEPA filtration. Filtered air circulates across the humidity pan to accelerate the humidifying process.

®

• LuxMed Hypoxia Chamber have microprocessor PID control to Intelligence control for CO2 density, temperature and alarm.

• Alarm system should remind the user to replace CO2 tank and ULPA filter.

• It can also be used as normal CO2 incubator.

• Blower should automatically stops when the door is opened, to minimize mixing of chamber and room air.

• Ductwork, plenums, and shelves are removable without tools.

®

• LuxMed Hypoxia Chamber have rounded corner which allows easy cleaning.

• The entire chamber should be made of stainless steel (SUS304).

• Heating of the chamber should automatically cut by safety device when temperature control failed or there is excessive heating over set point.

®

• LuxMed Hypoxia Chamber be provided with minimum two perforated shelves made of stainless steel which are resistant against rust and contamination.

®

• LuxMed Hypoxia Chamber have faster recovery and easy classification for various samples with at least 2 split doors.

®

• LuxMed Hypoxia Chamber have alarm system for low or high deviation of CO2 and temperature.

®

• LuxMed Hypoxia Chamber be provided with complete accessories to run the system at the installation site and one filled CO2 cylinder with three CO2 valve should

be quoted with the system.

• Warranty on the machine should be 2 years from the date of installation
