Technical Specifications:

Stand: Rigid & Heavy single mold aluminum die-cast stand.

Observation Head: Binocular/Trinocular head inclined at 45 and rotatable in 360.

Eyepiece: 10x WF (paired) anti-fungal eyepiece. H6x (paired) extra.

Nosepiece: Quadruple ball bearing revolving nose piece

Objectives: 4x/0.10, 10x/NA 0.25, 40x/NA 0.65(SL) & 100x/NA 1.25(SL) Oil imm

Stage: Size 120x140mm with co-axial controls for X & Y movement.

Focusing: Separate coarse and fine knobs reading up to 0.002mm.

Condenser: NA 1.25 fitted with iris diaphragm and blue filter holder.

Illumination: LED 3V with variable intensity control.

Power: AC input 100V-240V, 50/60 Hz ISO 9001, CE approved.

Packaging Contents: Styrofoam molded, Nylon Dust cover.
