Salient Features

  • 7" Colour Touchscreen HD Display

  • Android-based Operating System

  • Light Source: Halogen Lamp

  • Absorbance Range: 0–4.000 Abs with easy light source and filter replacement

  • Filter Wheel: 8 positions, 4 standard filters included (340 nm – 750 nm)

  • Standard Filters: 405 nm, 450 nm, 492 nm, 630 nm

    • Optional loading up to 8 filters

  • Calibration: Automatic calibration and positioning system

  • Diagnostics: Self-check for optical path and mechanical motion

  • Vibration Plate: Adjustable time and speed settings

  • Built-in software for instrument control and data analysis

  • USB connectivity

Specifications

Model: EMR4
HSN Code: 90275090

Standard Accessories

  • Main Instrument

  • Power Cord

  • Instruction Manual

  • Test Certificate

Parameter Specification
Make LABMAN
Filter Option 8-filter wheel
Standard Filters 405 nm, 450 nm, 492 nm, 630 nm (up to 8 optional)
Filter Bandwidth 8–10 nm
Reading Range 0.000 – 4.000 Abs
Wavelength Range 340 nm – 750 nm
Linear Range (405 nm) 0–3 Abs ±1%, 3–4 Abs ±2%
Accuracy (405 nm) ±1% (0–3 Abs), ±2% (3–4 Abs)
Repeatability CV 0.2% (0–3 Abs), ≤1.0% (3–4 Abs)
Measuring Speed < 6 sec for full 96-well plate
Resolution 0.001 Abs
Measurement Mode Standard & Fast mode
Light Source Halogen Lamp
Memory 200 programs & 100,000 results
Display 7" Colour Touchscreen
Interface 2 USB ports
Operating System Android
Calibration Automatic positioning system
Software Built-in software
Adjustable Time & Speed Yes
Power 60 W
Power Supply AC 220 V / 50 Hz
Dimensions 560 × 400 × 325 mm
Gross Weight 11 kg



Software Functions (Shown in Interface)

  • Standard Curve Generation

  • Choose Hole Type

  • Wavelength Absorbance Value Processing Method

  • Instrument Self-Test

  • Filter Setup

  • Microplate Layout Settings

(These features are shown in the software interface screens in the catalogue.)
