SALIENT FEATURES
Suitable for High Temperature Application upto 300 C
RS232C Interface, Selectable Speed
LCD Display for Viscometer, LED for Thermosel System
Temperature Controller - Set Temp. & real Temp. Display
Small Sample Volume and insulated sample chamber.
Direct display viscosity, speed, percent torque, spindle number,
Temperature, etc.
21 Spindle Measurement range: 50~500K
th 27 Spindle Measurement range: 250~2.5k
th 28 Spindle Measurement range: 500~5M
th 29 Rotor Spindle Measurement Range: 1K~10M
K = 1000mPa
M = 1000000mPa
SPECIFICATIONS:
|
MODEL |
LMDV300H |
|
Make |
LABWAN |
|
Measuring Range mpa.s |
50 ~ 1,00,00,000 |
|
No of Spindle |
4 (21,27,28,29) |
|
Speed range (r.p.m.) |
0.1 to 200 |
|
Accuracy |
±1%(FS) |
|
Repeatability |
±0.5% (FS) |
|
Sample capacity |
10 - 20ml |
|
Temperature control range |
RT +5 ~ 300 o o C C |
|
Temperature Accuracy |
±0.1 C |
|
Display |
LCD |
|
Output |
RS232C Interface |
|
Power supply |
Adaptor, Using AC 220V / 50Hz |
|
Packing Dimension (LxWxH) |
(395 x 345 x 500mm) + (405 x 355 x 380mm) |
|
Gross weight |
(Main Instrument + Thermosel) 14kg (9kg +5kg ) |
SALIENT FEATURES
Suitable for High Temperature Application upto 300 C
RS232C Interface, Selectable Speed
LCD Display for Viscometer, LED for Thermosel System
Temperature Controller - Set Temp. & real Temp. Display
Small Sample Volume and insulated sample chamber.
Direct display viscosity, speed, percent torque, spindle number,
Temperature, etc.
21 Spindle Measurement range: 50~500K
th 27 Spindle Measurement range: 250~2.5k
th 28 Spindle Measurement range: 500~5M
th 29 Rotor Spindle Measurement Range: 1K~10M
K = 1000mPa
M = 1000000mPa
SPECIFICATIONS:
|
MODEL |
LMDV300H |
|
Make |
LABWAN |
|
Measuring Range mpa.s |
50 ~ 1,00,00,000 |
|
No of Spindle |
4 (21,27,28,29) |
|
Speed range (r.p.m.) |
0.1 to 200 |
|
Accuracy |
±1%(FS) |
|
Repeatability |
±0.5% (FS) |
|
Sample capacity |
10 - 20ml |
|
Temperature control range |
RT +5 ~ 300 o o C C |
|
Temperature Accuracy |
±0.1 C |
|
Display |
LCD |
|
Output |
RS232C Interface |
|
Power supply |
Adaptor, Using AC 220V / 50Hz |
|
Packing Dimension (LxWxH) |
(395 x 345 x 500mm) + (405 x 355 x 380mm) |
|
Gross weight |
(Main Instrument + Thermosel) 14kg (9kg +5kg ) |
- Regular price
- Rs.0.00
- Delivery Period :5-7 Working Days
- Replacement :3 Days Replacement as standard, Free of Cost
- Dedicated Support :Support from 9:30 AM to 6:00 PM everyday
Product Description
