The Labmart Type B3 Ultra Micro Fluorescence Cuvette is a precision quartz optical cell designed for fluorescence and fluorometric measurements using very small sample volumes. It features four polished windows, a 10 mm path length, 15 mm Z-height, black-wall construction and PTFE closure options, making it suitable for sensitive fluorescence measurements where sample conservation is important.

Product Overview

The Type B3 Ultra Micro Fluorescence Cuvette is designed for fluorescence applications requiring very low sample volumes while maintaining four-sided optical access.

The standard configuration features a 10 mm path length, 15 mm Z-height, black-wall quartz construction and dimensions of 12.5 × 12.5 × 45 mm. Multiple ultra-micro sample volumes are available, from 10 µL to 400 µL.

The cuvette is available with either a PTFE cover or PTFE stopper, with the listed configurations supplied as matched pairs.

The black-wall design is particularly important for fluorescence applications because masking unwanted light paths can help preserve measurement sensitivity. The correct Z-height should be selected according to the centre-beam height of the fluorescence instrument.

Key Features and Benefits

• Ultra-micro fluorescence cuvette
• Four polished optical windows
• 10 mm path length
• 15 mm standard Z-height
• Black-wall construction
• Quartz optical material
• Ultra-low sample volumes from 10 µL to 400 µL
• PTFE cover option
• PTFE stopper option
• Supplied as a unit pair
• Compact 12.5 × 12.5 × 45 mm design
• Alternative Z-heights available on request
• Suitable for fluorescence and fluorometric measurements
• UV quartz configuration supports deep-UV applications

4. Technical Specifications

Type B3 Standard Volume Variants

*The 50 µL / 35 mm configuration has a special dimensional/order-code configuration in the supplied product data; verify the exact Z-height designation before publishing it as a standard Shopify variant.

Additional Z-heights: 3 mm, 8.5 mm, 15 mm and 20 mm are listed as available on request.

5. Applications

• Fluorescence spectroscopy
• Fluorometric analysis
• Ultra-low-volume fluorescence measurements
• Pharmaceutical research
• Biochemical research
• Biotechnology research
• Molecular biology
• Protein analysis
• Nucleic-acid research
• Chemical analysis
• Life-science research
• Analytical R&D

6. Suitable For

• Fluorometers
• Fluorescence spectrometers
• Ultra-micro fluorescence applications
• Pharmaceutical laboratories
• Biotechnology laboratories
• Biochemistry laboratories
• Molecular biology laboratories
• University research laboratories
• Analytical laboratories
• R&D facilities

7. Product Benefits

• Ultra-low sample consumption: configurations begin at only 10 µL.
• Four polished windows: provides optical access for fluorescence excitation and emission geometry.
• Black-wall construction: helps reduce unwanted light transmission and supports fluorescence sensitivity.
• Quartz construction: suitable for UV and fluorescence applications.
• 190–2500 nm transmission range: supports a broad optical range for the listed UV quartz configuration.
• Multiple volume choices: enables users to select the cuvette according to sample availability.
• 15 mm Z-height: suitable for instruments requiring this centre-beam height.
• PTFE closure options: provides flexibility between cover and stopper configurations.
• Matched pair supply: useful for applications requiring paired optical cells.
