The Labmart Type B1 Macro Fluorescence Cuvette is a precision optical cuvette designed for fluorescence and fluorometric measurements. It features four optically polished windows, fire-fused construction, precise optical geometry, and chemical-resistant construction for reliable laboratory analysis. Available in optical glass, Pyrex glass, UV quartz, and IR quartz configurations.

Product Overview

The Type B1 Macro Fluorescence Cuvette is designed for fluorescence spectroscopy where optical access through multiple faces is important for excitation and emission measurements. Unlike conventional two-window spectrophotometer cuvettes, the B1 configuration provides four polished optical windows and a polished base.

The cell is manufactured using fire-flame or thermal-fusing techniques, eliminating the need for glued or fritted side assembly. This creates a robust, integrated construction with highly transparent fused sides.

Precision optical-path alignment maintains the light-path tolerance within ±0.1 mm, while the fused construction provides good integrity and helps prevent leakage and cross-contamination.

Key Features and Benefits

• Four optically polished windows for fluorescence measurements
• Optically polished base
• Light-path tolerance: ±0.1 mm
• Fire-flame/thermal-fused construction
• No glued or fritted side assembly
• High optical transparency of fused connected sides
• Good acid, alkali and organic-solvent resistance
• Fused sides help prevent adherence of testing materials
• Designed to minimize cross-pollution concerns
• Well-consistent and well-matched cells
• Hand-finished optical polishing
• Rigorous inspection before dispatch
• Available in Optical Glass, Pyrex Glass, UV Quartz and IR Quartz
• Pyrex Glass available for 10 mm light path
• Light paths available from 1–100 mm
• Includes PTFE cover

4. Technical Specifications

Note: Dimensions, volume and wavelength range above refer to the listed 10 mm quartz configuration. Other light-path and material combinations can have different dimensions or working volumes.

5. Applications

• Fluorescence spectroscopy
• Fluorometric analysis
• Pharmaceutical research
• Biochemical analysis
• Molecular biology research
• Chemical analysis
• Environmental testing
• Life-science research
• Analytical laboratory applications
• Research and development laboratories
• Fluorescence-based quantitative measurements

6. Suitable For

• Fluorescence spectrometers
• Fluorometers
• Research laboratories
• Pharmaceutical laboratories
• Biotechnology laboratories
• Chemical laboratories
• University and academic laboratories
• Quality-control laboratories
• R&D facilities requiring precision fluorescence cells

7. Product Benefits

• Four-sided optical access supports fluorescence measurement geometry.
• Precision optical path helps maintain consistent measurement conditions.
• ±0.1 mm light-path tolerance supports accurate optical positioning.
• Fire-fused construction provides a robust alternative to glued assembly.
• Chemical-resistant construction supports use with a wide range of laboratory solutions.
• Polished optical surfaces improve optical transmission and measurement consistency.
• Matched-cell construction supports comparative analytical measurements.
• Multiple material options allow selection according to wavelength and application requirements.
• PTFE cover helps protect the sample from contamination and evaporation during use.
