Technical Specifications:

OBSERVATION HEAD: Monocular head Inclined at 45 rotatable 360 lockable at any angle. Eyepiece tube focusable to match objectives tube length.

EYEPIECE: Lockable,anti-fungal KEOWA Wide Field HKW 10x A. R. Coated eyepiece

NOSEPIECE: Quadruple nosepiece precisely built- on ball bearing, provides lifelong smooth rotation through a built-in positive click stop and rubber grip. Totally, dust proof design.

OBJECTIVES: KEOWAS-Plan Achromatic objectives 4x/NA 0.10, 10x/NA 0.25, 40x/NA 0.65 (SL) and 100x/NA 1.25 (SL) oil immersion, anti-fungal.

MECHANICAL STAGE: Double Plated Rectangular stage (Ball Bearing Type) withasurfaceof120mmx140mmhaving low positioned co-axial controls. BothX&Yaxishavinggraduatedscale&verniersreadingto0.1mm.

CO-AXIAL FOCUSING: Co-axial fine and coarse focusing control with ball bearing guideways based on four stage gear reduction system, provides the degree of reduction sensitivity, free from any BACK LASH & large knobs provide a soft and sophisticated touch to the microscope.

TENSION CONTROL RING: Enable you to adjust the tension on coarse focussing knobs.

CONDENSER: A focusable Abbe two lens type NA 1.25 condenser with iris diaphragm and swing out filter holder with Blue filter. Rack& pinion movement on metal guides.

EXTRA LARGE BASE: Single mold sturdy stand with antirust materials.

ILLUMINATION: Built-inbase illumination special quality HALOGEN bulb 6V-20Wor 3W LED illumination with intensity controlled power supply.

OPTIONAL ACCESSORIES: High resolution digital camera, Image Analysis Software.
