Product Description

The MS-H280-B1000 LCD Digital Magnetic Stirrer is a complete laboratory solution that presents sophisticated stirring and a dedicated heating mantle for a 1000 mL beaker. This advanced digital magnetic stirrer provides dependable electric heating up to 280°C, in addition to stable stirring from 200-1500 rpm. The LCD display offers users a clear view of both the speed and temperature of the stirring process at any given moment, which helps facilitate process control. There are also enhanced safety systems that provide for over-temperature and residual heat warnings. This lab stirrer with temperature control is ideal for chemical processing, sample preparation, and other educational uses where it requires mixing and heating within 1000 mL.

Key Features

Performance

  • Electric heating capability up to 280°C
  • Smooth magnetic stirring from 200–1500 rpm
  • Optimized for 1000 mL flat-bottom beakers
  • Powerful performance for viscous samples

Design

  • Integrated heating mantle for 1000 mL beakers
  • LCD digital display for real-time parameter monitoring
  • Ceramic-coated aluminum heating surface
  • Compact benchtop design

Safety

  • Advanced over-temperature protection system
  • 'HOT' warning indicator above 50°C
  • Brushless DC motor technology
  • Dual safety circuit design

Technical Specifications

Functionality

  • Stirring Speed: 200–1500 rpm (±20 rpm)
  • Heating Range: Room temperature to 280°C
  • Display Type: LCD digital
  • Weight: 3.7 kg

Applications

  • Synthesis: Suitable for chemical synthesis processes
  • Processing: Ideal for sample preparation and heating
  • Education: Useful for educational laboratory work
  • Quality Control: Supports quality-control procedures

Physical Structure

  • Compatible Beaker: 1000 mL flat-bottom beakers
  • Heating Mantle Inner Diameter: 118.75 mm
  • Work Plate Material: Ceramic-coated aluminum
  • Dimensions: 295 × 160 × 160 mm

Power & Safety

  • Motor Type: Brushless DC motor
  • Heating Power: 440W
  • Over-temperature Protection: 420°C
  • Residual Heat Warning: 'HOT' indicator activates above 50°C
