The Labmart MTVM50 Multi Tube Vortex Mixer is a high-throughput laboratory mixer designed to simultaneously mix up to 50 tubes/samples for efficient and uniform sample blending. It provides a variable speed range of 500–3000 RPM, 4 mm orbital amplitude, and both impulse and continuous operating modes.

The MTVM50 features a low-noise brushless motor, LED display for speed and timing, accurate speed control, timer function and interchangeable sponge tube racks in 6 mm, 8 mm, 15 mm, 25 mm and 29 mm configurations. labman-multi-tube-vortex-mixer-…

3. Detailed Product Description

Product Overview

The Labmart MTVM50 Multi Tube Vortex Mixer is designed for laboratories that need to mix multiple tubes simultaneously. Its multi-tube configuration allows up to 50 samples to be mixed at the same time, making it suitable for higher-throughput sample preparation and routine laboratory workflows.

The mixer uses horizontal orbital shaking with a 4 mm amplitude and provides a variable speed range of 500–3000 RPM. Speed can be adjusted in 1 RPM increments, allowing precise control over mixing conditions. labman-multi-tube-vortex-mixer-… labman-multi-tube-vortex-mixer-…

The system includes five types of replaceable sponge test-tube racks, accommodating tube hole sizes of 6 mm, 8 mm, 15 mm, 25 mm and 29 mm. The accessory page of the catalogue visually shows all five rack configurations. labman-multi-tube-vortex-mixer-…

4. Key Features & Benefits

• 50-Sample Capacity: Mixes up to 50 tubes/samples simultaneously.
• 500–3000 RPM Speed Range: Provides a wide range of adjustable mixing speeds.
• 1 RPM Speed Adjustment: Allows fine speed adjustment.
• 4 mm Amplitude: Provides the specified horizontal orbital shaking movement.
• Horizontal Orbital Shaking: Designed for uniform sample mixing.
• Two Operating Modes: Supports impulse and continuous operation.
• LED Display: Displays operating information including speed and timing.
• Timer Function: Enables controlled timed mixing.
• 1-Second Time Display Accuracy: Provides precise time indication.
• 1-Minute Time Adjustment: Allows the timer to be adjusted in 1-minute increments.
• Brushless Motor: Designed for low-noise operation.
• Five Interchangeable Sponge Racks: Supports multiple tube sizes.
• 4 kg Maximum Load Capacity: Suitable for multi-tube sample processing within the specified load.
• Accurate Speed Control: Provides precise speed adjustment for repeatable mixing.
• Compact Benchtop Design: Instrument dimensions are 385 × 235 × 420 mm.

The catalogue lists these features on page 2, while page 3 visually presents the five supplied sponge rack configurations. labman-multi-tube-vortex-mixer-… labman-multi-tube-vortex-mixer-…

5. Technical Specifications

The specifications above are taken from the MTVM50 technical specification table in the supplied catalogue. labman-multi-tube-vortex-mixer-…

6. Tube Capacity & Rack Configuration

The MTVM50 is designed to accommodate a maximum of 50 tube holes.

It includes five replaceable sponge test-tube rack configurations:

The catalogue's page 3 shows the five rack configurations individually, including the 6 mm × 50, 8 mm × 50, 15 mm × 50, 25 mm × 15 and 29 mm × 15 arrangements. labman-multi-tube-vortex-mixer-…

7. Operating Modes

The MTVM50 provides two operating modes:

Impulse Mode

Designed for intermittent mixing operation where the mixing action can be applied as required.

Continuous Mode

Designed for continuous mixing over the selected operating period.

The source identifies the instrument as having 2 modes and specifically lists Impulse & Continuous mode. labman-multi-tube-vortex-mixer-…

8. Applications

The catalogue describes a multi-tube vortex mixer as a laboratory device for simultaneously mixing multiple tubes, providing efficient and uniform blending of samples. It identifies the instrument as particularly suitable for high-throughput laboratory applications, helping save time and increase productivity. labman-multi-tube-vortex-mixer-…

Based on the documented function, the MTVM50 is suitable for:

• Multi-tube sample mixing
• Laboratory sample preparation
• High-throughput sample processing
• Simultaneous tube mixing
• Uniform sample blending
• Research laboratory workflows
• Routine laboratory sample processing

9. Suitable For

• Research laboratories
• Biotechnology laboratories
• Pharmaceutical laboratories
• Life-science laboratories
• Analytical laboratories
• Quality-control laboratories
• Academic laboratories
• Clinical research laboratories
• High-throughput sample preparation workflows

Specific application compatibility with individual assays or tube types beyond the listed rack dimensions is not specified in the supplied source.

10. FAQs

1. What is the Labmart MTVM50?

The MTVM50 is a Multi Tube Vortex Mixer designed to mix multiple laboratory tubes simultaneously.

2. How many tubes can it mix?

The system provides a maximum of 50 tube holes, depending on the installed rack.

3. What is the speed range?

The speed range is 500–3000 RPM.

4. How precisely can the speed be adjusted?

The speed adjustment increment is 1 RPM.

5. What is the shaking amplitude?

The specified amplitude is 4 mm.

6. What type of motion does the mixer use?

It uses horizontal orbital shaking.

7. What operating modes are available?

The MTVM50 provides impulse and continuous modes.

8. Does it have a timer?

Yes. The MTVM50 includes a timer function.

9. What is the time display accuracy?

The specified time display accuracy is 1 second.

10. What is the timer adjustment increment?

The time adjustment increment is 1 minute.

11. What tube sizes are supported?

The supplied sponge racks have holes of:

• 6 mm
• 8 mm
• 15 mm
• 25 mm
• 29 mm

12. How many rack types are supplied?

The catalogue specifies 5 types of replaceable sponge racks.

13. What is the maximum load capacity?

The maximum load capacity is 4 kg.

14. What motor does it use?

The specification identifies a brushless motor.

15. What is the power consumption?

The specified power is 60 W.

16. What power supply is required?

AC 220 V / 50–60 Hz.

17. What are the instrument dimensions?

385 × 235 × 420 mm (L × W × H).

18. What is the gross weight?

The gross weight is 17 kg.

19. What is the HSN code?

The specified HSN code is 84798200. labman-multi-tube-vortex-mixer-…
