The Labmart LMPH1P Portable pH Meter is a laboratory-grade portable instrument for accurate pH, mV and temperature measurement. It offers a -2.00 to 20.00 pH range, 0.01 pH resolution, ±0.01 pH accuracy, automatic temperature compensation, 1–3 point calibration, 100-data memory, USB connectivity and LCD display with white backlight.

Product Overview

The LMPH1P Portable pH Meter is designed for routine laboratory measurement of pH, oxidation-reduction potential (mV) and temperature. Its portable format makes it suitable for laboratories and applications where measurements need to be performed at different locations.

The meter supports 1 to 3-point calibration with automatic recognition of USA and NIST buffer sets. Automatic electrode diagnosis helps the user assess the condition of the pH electrode, while the auto-read function detects and locks the measurement endpoint.

The instrument provides automatic or manual temperature compensation, stores up to 100 data sets, and includes a USB interface for data transfer or connection to a power adapter.

Key Features & Benefits

• Portable pH measurement system
• pH range: -2.00 to 20.00 pH
• 0.01 pH resolution
• ±0.01 pH accuracy
• 1–3 point calibration
• Automatic USA and NIST buffer recognition
• Automatic electrode diagnosis
• Automatic temperature compensation
• Manual or automatic temperature compensation selection
• mV range: ±1999 mV
• 1 mV mV resolution
• ±1 mV mV accuracy
• Auto-read endpoint detection
• Manual hold function
• LCD display with white backlight
• 100-data-set memory
• USB interface
• BNC electrode connection
• Automatic power-off
• Approximately 150-hour battery life without backlight
• Carrying case available as standard supply

4. Technical Specifications

5. Applications

The LMPH1P is suitable for:

• Laboratory pH measurement
• Water-quality testing
• Chemical analysis
• Pharmaceutical laboratory testing
• Food and beverage testing
• Environmental testing
• Research and development
• Quality-control laboratories
• Academic and teaching laboratories
• General liquid-sample pH measurement
• mV/ORP-related measurements where an appropriate electrode is used

6. Suitable For

The LMPH1P is suitable for:

• Chemical laboratories
• Pharmaceutical laboratories
• Food and beverage laboratories
• Environmental laboratories
• Water-testing laboratories
• Research institutions
• Quality-control departments
• Universities and colleges
• Industrial laboratories
• Field laboratory applications

7. FAQs

1. What is the LMPH1P used for?

The LMPH1P is a portable meter for measuring pH, mV and temperature in suitable samples.

2. What is the pH measurement range?

The pH range is -2.00 to 20.00 pH.

3. What is the pH resolution?

The resolution is 0.01 pH.

4. What is the pH accuracy?

The specified accuracy is ±0.01 pH.

5. How many calibration points are available?

The LMPH1P supports 1 to 3-point calibration.

6. Which calibration buffers are supported?

It supports USA buffers pH 4.01, 7.00 and 10.01 and NIST buffers pH 4.01, 6.86 and 9.18.

7. Does the meter have automatic temperature compensation?

Yes. Temperature compensation can be selected as manual or automatic over the specified compensation range.

8. What is the mV measurement range?

The mV range is ±1999 mV, with 1 mV resolution and ±1 mV accuracy.

9. How much measurement data can be stored?

The meter can store up to 100 data sets.

10. Does the LMPH1P have USB connectivity?

Yes. It has a USB interface for data transfer or connection to a power adapter.

11. What type of electrode connector does it use?

The instrument uses a BNC connector.

12. What is included with the meter?

The standard accessories include the main instrument, pH electrode, pH buffer pouch, instruction manual and test certificate.
