The Labmart LMMS300 Hotplate Magnetic Stirrer is a microprocessor-controlled laboratory heating and stirring system designed for simultaneous sample heating and magnetic stirring. It provides a maximum plate-surface temperature of 300°C, stirring speed up to 1250 RPM, and a maximum volume of 2000 mL.

The LMMS300 features an LCD display, digital speed control, programmable temperature and stirring parameters, 999-minute timer and automatic temperature control using an ATC temperature probe. Its 135 × 135 mm stainless-steel top plate provides a durable laboratory heating surface.

3. Detailed Product Description

Product Overview

The Labmart LMMS300 Hotplate Magnetic Stirrer combines controlled heating and magnetic stirring in one compact laboratory instrument.

The system is operated using a digital control CPU, which regulates heating up to 300°C and controls stirring speed through the keypad. The selected stirring speed is indicated on the display using a bar-graph indication.

The LMMS300 is also programmable, allowing the operator to set the objective temperature, hold temperature, stirring time and stirring speed. For more accurate temperature control, an ATC temperature probe can be connected and placed inside the glass container being stirred to measure and maintain the desired temperature.

4. Key Features & Benefits

• Hotplate + Magnetic Stirrer in One Unit
• 300°C Maximum Plate-Surface Temperature
• 1250 RPM Maximum Stirring Speed
• 2000 mL Maximum Volume
• Microprocessor / CPU Control
• Digital Speed Control
• Programmable Temperature and Stirring Parameters
• Automatic Temperature Control (ATC)
• ATC Temperature Probe Included
• LCD Display
• 999-Minute Timer
• 135 × 135 mm Stainless-Steel Top Plate
• Temperature Control Through External Probe
• Digital Keypad Operation
• Stirring Speed Indication
• Compact Benchtop Laboratory Design

5. Technical Specifications

6. Heating Performance

The LMMS300 provides a maximum plate-surface temperature of 300°C.

Temperature Accuracy

The microprocessor controls the heating system, while the ATC probe can be used to measure and maintain the desired temperature of the sample rather than relying only on the plate temperature.

7. Stirring Performance

The LMMS300 provides:

• Maximum speed: 1250 RPM
• Maximum volume: 2000 mL
• Digital speed control
• Keypad-based speed adjustment
• Speed indication on display
• Programmable stirring speed
• Programmable stirring time

This makes the unit suitable for controlled mixing and heating of laboratory solutions.

8. Automatic Temperature Control

The Automatic Temperature Control (ATC) function allows the temperature of the sample to be monitored directly.

How ATC Works

1. Connect the supplied ATC temperature probe.
2. Place the probe inside the glass container containing the sample.
3. Set the desired temperature.
4. The probe measures the sample temperature.
5. The control system regulates heating to maintain the desired temperature.

This provides more meaningful temperature control of the sample compared with relying solely on the hotplate surface temperature.

9. Programmable Operation

The LMMS300 allows the operator to configure:

• Objective temperature
• Hold temperature
• Stirring time
• Stirring speed

This programmable functionality makes the instrument suitable for repeatable laboratory heating and mixing procedures.

10. Control & Display

The LMMS300 uses a digital control CPU with an LCD display.

The control system provides:

• Temperature setting
• Temperature monitoring
• Digital stirring-speed control
• Stirring-speed indication
• Programmable operating parameters
• Timer control
• Automatic temperature control

The supplied catalogue also shows the instrument with a stand assembly for the ATC probe.

11. Applications

The LMMS300 is suitable for laboratory procedures requiring simultaneous heating and stirring, including:

• Solution preparation
• Reagent preparation
• Chemical mixing
• Sample heating
• Controlled laboratory reactions
• Buffer preparation
• Pharmaceutical laboratory work
• Research and development
• Quality-control laboratories
• General laboratory mixing and heating

Specific chemical compatibility or application-specific performance should be evaluated according to the sample and vessel being used.

12. Suitable For

• Chemical laboratories
• Pharmaceutical laboratories
• Research laboratories
• Biotechnology laboratories
• Analytical laboratories
• Quality-control laboratories
• Educational laboratories
• Industrial R&D laboratories
• General-purpose laboratory sample preparation3

13. FAQs

1. What is the Labmart LMMS300?

The LMMS300 is a Hotplate Magnetic Stirrer combining laboratory heating and magnetic stirring.

2. What is the maximum temperature?

The maximum plate-surface temperature is 300°C.

3. What is the maximum stirring speed?

The maximum stirring speed is 1250 RPM.

4. What is the maximum sample volume?

The specified maximum volume is 2000 mL (2 L).

5. What is the hotplate size?

The stainless-steel top plate measures 135 × 135 mm.

6. What is the temperature accuracy?

The specified accuracy is:

• ±1°C below 100°C
• ±3°C below 300°C

7. Does the LMMS300 have automatic temperature control?

Yes. The instrument provides Automatic Temperature Control (ATC) using a temperature probe.

8. Is the ATC probe included?

Yes. The ATC probe and its stand set are listed among the standard accessories.

9. Can the stirring speed be programmed?

Yes. The stirring speed can be set through the digital control system.

10. Can the temperature be programmed?

Yes. The operator can set the objective and hold temperature.

11. Does the LMMS300 have a timer?

Yes. It has a 999-minute timer.

12. What type of display does it use?

The instrument uses an LCD display.

13. What is the plate material?

The top plate is made from stainless steel.

14. What power supply is required?

AC 220 V, 50/60 Hz.

15. What are the packing dimensions?

310 × 255 × 190 mm (L × W × H).

16. What is the gross weight?

3 kg.

17. What is the HSN code?

84798200.
