The LABMART DSVP66 Double Stage Rotary Vane Vacuum Pump is a two-stage rotary vane vacuum pump designed for medium- and high-vacuum applications. It operates at 1400 rpm and achieves an ultimate pressure of 6 × 10⁻² Pa. The pump uses an air-cooled system and has a 1 L oil capacity.

The DSVP66 features a double anti-return oil device and is designed to prevent oil leakage and contamination. The catalogue identifies it as suitable for medium and high vacuum levels, including applications such as freeze dryers.

Product Specifications

Specification Details
Model DSVP66
Make Labmart
Pump Type Double Stage Rotary Vane Vacuum Pump
Number of Stages Double Stage
Noise Level 66 dB
Inlet Diameter 30 mm
Outer Diameter 40 mm
Rotation Speed 1400 rpm
Ultimate Pressure 6 × 10⁻² Pa
Cooling Method Air Cooled
Oil Capacity 1 L
Ambient Temperature 5°C to 35°C
Phase Single Phase
Power Supply AC 220 V / 50 Hz
Motor Power 0.37 kW
Vacuum Pump Dimensions (L × W × H) 480 × 180 × 240 mm
Packing Dimensions (L × W × H) 600 × 235 × 410 mm
Net Weight 19 kg
Gross Weight 25 kg
Packing Type Wooden Box Packing
HSN Code 84141090

Key Features

  • Double-stage rotary vane vacuum pump for medium- and high-vacuum applications.

  • Ultimate pressure of 6 × 10⁻² Pa.

  • 1400 rpm rotation speed.

  • 66 dB noise level as specified in the catalogue.

  • Double anti-return oil device to help prevent oil backflow.

  • No oil leak / no pollution design as stated by the manufacturer.

  • Air-cooled operation.

  • 1 L oil capacity.

  • Suitable for medium and high vacuum levels.

  • Suitable for freeze dryers and other vacuum equipment.

  • Single-phase AC 220 V / 50 Hz power supply.

  • Compact construction with a 19 kg net weight.

Applications

The DSVP66 is suitable for laboratory and industrial equipment requiring medium to high vacuum, including:

  • Freeze dryers

  • Vacuum drying systems

  • Laboratory vacuum systems

  • Vacuum processing equipment

  • Other medium- and high-vacuum applications

The attached catalogue specifically states that the DSVP66 is suitable for freeze dryers and similar applications.

Standard Accessories

The DSVP66 is supplied with:

  • Main Instrument

  • Instruction Manual

  • Test Certificate
