Double Beam UV-Vis. Spectrophotometer LMSPUV1920 - Labmart.in
  • Double Beam UV-Vis. Spectrophotometer LMSPUV1920 - Labmart.in

The Double Beam UV-Vis Spectrophotometer LMSPUV1920 is a high-performance analytical instrument designed for accurate UV and visible spectrum analysis in pharmaceutical laboratories, research institutes, biotechnology facilities, chemical industries, environmental testing laboratories, and academic institutions. Featuring a precision double beam optical system, the instrument simultaneously measures sample and reference signals to provide highly stable and reliable analytical results.

The LMSPUV1920 is equipped with a long optical path design, high-resolution grating system, 6-inch LCD display, and advanced software functions for spectrum scanning, kinetics analysis, DNA/protein testing, and multi-wavelength measurements. Its rigid 16 mm die-cast aluminum optical base enhances instrument stability and improves measurement accuracy during routine and advanced laboratory applications.

Designed for dependable analytical performance, the spectrophotometer offers excellent wavelength accuracy, low stray light, high photometric stability, and USB connectivity for efficient data management. The LMSPUV1920 is ideal for laboratories requiring precise quantitative and qualitative analysis with consistent and reproducible results

SALIENT FEATURES:

The two detectors are used to measure sample and reference respectively and simultaneously for optimizing measurement accuracy.
Lamp Selection enables conserving the life of D2 & Tungsten lamps. Real time clock for date & time stamping of results.
LIGHT PATH DESIGN: DOUBLE BEAM
LMSPUV1900 series double light design can prevent circuit fluctuation and stray light to ensure stability of the instrument.
LONG PATH LIGHT DESIGN
LMSPUV1900 series unique 520mm long light path design with greatly improved resolution.
16MM OPTICAL BASE
LMSPUV1900 series use a rigid 16mm diecast aluminum base as their optical mount to ensure the stability and reliability.
6 INCHES LCD DISPLAY
LMSPUV1900 series have a 6 inches LCD display to show results and curves directly on the screen.
SOFTWARE FUNCTIONS
Multi functions operated directly on the spectrophotometer and display the test results' curve and data: wavelength scanning,
standard curve, kinetics, multi wavelength scanning, DNA/protein test.
PERFECT CALIBRATION SYSTEM
All baseline, wavelength, dark current can be calibrated automatically to keep good running conditions.
DATA OUTPUT
LMSPUV1900 series are equipped with USB port to connect with a PC.

Specifications LMSPUV1920 LMSPUV1928
Sample Cell Holder 10mm Cell Holder 8 Cell Holder Programmable 10mm
Reference Cell Holder 10mm Cell Holder 10mm Cell Holder
Make LABMAN LABMAN
Optical System Double Beam (1200 Lines/mm Grating) Double Beam (1200 Lines/mm Grating)
Wavelength Range 190 – 1100 nm 190 – 1100 nm
Bandwidth 1.0, 2.0, 4.0 nm (Variable) 1.0, 2.0, 4.0 nm (Variable)
Wavelength Accuracy ±0.3 nm ±0.3 nm
Wavelength Repeatability ±0.2 nm ±0.2 nm
Scanning Speed Fast, Medium & Low Fast, Medium & Low
Photometric Accuracy ±0.3%T ±0.3%T
Photometric Repeatability 0.2%T 0.2%T
Photometric Range -0.3 – 3A, 0 – 200%T, 0 – 9999C -0.3 – 3A, 0 – 200%T, 0 – 9999C
Stability ±0.001A/h @ 500nm ±0.001A/h @ 500nm
Baseline Flatness ±0.001A/h ±0.001A/h
Noise ±0.001A/h ±0.001A/h
Stray Light ≤0.05%T @ 220nm, 360nm ≤0.05%T @ 220nm, 360nm
Data Output Port USB USB
Printer Port Parallel Port Parallel Port
Display LCD LCD
Light Source D2 Lamp & Tungsten Halogen Lamp (W Lamp) D2 Lamp & Tungsten Halogen Lamp (W Lamp)
Detector Silicon Photodiode Silicon Photodiode
Power Supply AC 220V, 50/60Hz AC 220V, 50/60Hz
Dimension 795 × 595 × 395 mm 795 × 595 × 395 mm
Weight 34 kg 35 kg

Standard Accessories

  • Main Instrument

  • 10mm Glass Cuvette – 4 pcs

  • 10mm Quartz Cuvette – 2 pcs

  • Dongle

  • Pen Drive

  • Power Cable

  • Dust Cover

  • Instruction Manual

  • Test Certificate

Optional Accessories

  • Peltier / Sipper System

  • Multi Cell Holder (Up to 50 mm)

Labman

Double Beam UV-Vis. Spectrophotometer I Variable Bandwidth I FREE ONSITE INSTALLATION

SKU LMSPUV1928
Rs.320,000.00
Rs.292,000.00

The Double Beam UV-Vis Spectrophotometer LMSPUV1920 is a high-performance analytical instrument designed for accurate UV and visible spectrum analysis in pharmaceutical laboratories, research institutes, biotechnology facilities, chemical industries, environmental testing laboratories, and academic institutions. Featuring a precision double beam optical system, the instrument simultaneously measures sample and reference signals to provide highly stable and reliable analytical results.

The LMSPUV1920 is equipped with a long optical path design, high-resolution grating system, 6-inch LCD display, and advanced software functions for spectrum scanning, kinetics analysis, DNA/protein testing, and multi-wavelength measurements. Its rigid 16 mm die-cast aluminum optical base enhances instrument stability and improves measurement accuracy during routine and advanced laboratory applications.

Designed for dependable analytical performance, the spectrophotometer offers excellent wavelength accuracy, low stray light, high photometric stability, and USB connectivity for efficient data management. The LMSPUV1920 is ideal for laboratories requiring precise quantitative and qualitative analysis with consistent and reproducible results

SALIENT FEATURES:

The two detectors are used to measure sample and reference respectively and simultaneously for optimizing measurement accuracy.
Lamp Selection enables conserving the life of D2 & Tungsten lamps. Real time clock for date & time stamping of results.
LIGHT PATH DESIGN: DOUBLE BEAM
LMSPUV1900 series double light design can prevent circuit fluctuation and stray light to ensure stability of the instrument.
LONG PATH LIGHT DESIGN
LMSPUV1900 series unique 520mm long light path design with greatly improved resolution.
16MM OPTICAL BASE
LMSPUV1900 series use a rigid 16mm diecast aluminum base as their optical mount to ensure the stability and reliability.
6 INCHES LCD DISPLAY
LMSPUV1900 series have a 6 inches LCD display to show results and curves directly on the screen.
SOFTWARE FUNCTIONS
Multi functions operated directly on the spectrophotometer and display the test results' curve and data: wavelength scanning,
standard curve, kinetics, multi wavelength scanning, DNA/protein test.
PERFECT CALIBRATION SYSTEM
All baseline, wavelength, dark current can be calibrated automatically to keep good running conditions.
DATA OUTPUT
LMSPUV1900 series are equipped with USB port to connect with a PC.

Specifications LMSPUV1920 LMSPUV1928
Sample Cell Holder 10mm Cell Holder 8 Cell Holder Programmable 10mm
Reference Cell Holder 10mm Cell Holder 10mm Cell Holder
Make LABMAN LABMAN
Optical System Double Beam (1200 Lines/mm Grating) Double Beam (1200 Lines/mm Grating)
Wavelength Range 190 – 1100 nm 190 – 1100 nm
Bandwidth 1.0, 2.0, 4.0 nm (Variable) 1.0, 2.0, 4.0 nm (Variable)
Wavelength Accuracy ±0.3 nm ±0.3 nm
Wavelength Repeatability ±0.2 nm ±0.2 nm
Scanning Speed Fast, Medium & Low Fast, Medium & Low
Photometric Accuracy ±0.3%T ±0.3%T
Photometric Repeatability 0.2%T 0.2%T
Photometric Range -0.3 – 3A, 0 – 200%T, 0 – 9999C -0.3 – 3A, 0 – 200%T, 0 – 9999C
Stability ±0.001A/h @ 500nm ±0.001A/h @ 500nm
Baseline Flatness ±0.001A/h ±0.001A/h
Noise ±0.001A/h ±0.001A/h
Stray Light ≤0.05%T @ 220nm, 360nm ≤0.05%T @ 220nm, 360nm
Data Output Port USB USB
Printer Port Parallel Port Parallel Port
Display LCD LCD
Light Source D2 Lamp & Tungsten Halogen Lamp (W Lamp) D2 Lamp & Tungsten Halogen Lamp (W Lamp)
Detector Silicon Photodiode Silicon Photodiode
Power Supply AC 220V, 50/60Hz AC 220V, 50/60Hz
Dimension 795 × 595 × 395 mm 795 × 595 × 395 mm
Weight 34 kg 35 kg

Standard Accessories

  • Main Instrument

  • 10mm Glass Cuvette – 4 pcs

  • 10mm Quartz Cuvette – 2 pcs

  • Dongle

  • Pen Drive

  • Power Cable

  • Dust Cover

  • Instruction Manual

  • Test Certificate

Optional Accessories

  • Peltier / Sipper System

  • Multi Cell Holder (Up to 50 mm)
Rs.320,000.00
Rs.292,000.00
Sample Cell Holder:
  • Delivery Period :5-7 Working Days
  • Replacement :3 Days Replacement as standard, Free of Cost
  • Dedicated Support :Support from 9:30 AM to 6:00 PM everyday
