Technical Specifications:

BASE: Single mold sturdy C stand with anti rust materials and extended base.

HEAD: Binocular Observation head inclined at 30º rotatable at 360º. IPD 55-75mm provided.

EYEPIECE: KEOWAWIDE FIELD HKW 10x paired with eye guards.

OBJECTIVES: KEOWA Semi Plan Achromatic Objectives, anti-fungus treated4x/NA 0.1010x/NA 0.2540x/NA 0.65 (Spring Loaded)100x/NA 1.25 (SL, oil immersion)

NOSEPIECE: Reverse angle Quadruple nosepiece revolves on ball bearing with rubber grip and positive click stop.

MECHANICAL STAGE: Right Hand Mechanical stage size 120mm X 140mm having low positioned co-axial controls on ball bearing. Spring clip double specimen holder Cross X&Y movement 60mm X 80mm.

FOCUSING SYSTEM: Low position Co-axial graduated coarse & fine focusing system with TENSION ADJUSTMENT RING provides a soft and sophisticated touch to the microscope.

Coarse Movement stroke: 20mm tension on the right.

SUB STAGE CONDENSER: Focusable Abbe Condenser centerable NA 1.25 with aspheric lens, filter holder, Iris Diaphragm movable on rack & pinion with BLUE filter. Vertical adjustment range:10mm.

ILLUMINATION: Built-in-base illumination system with 6V 20W Halogen lamp or 3W LED lamp with  intensity controlled power supply & day light reflector/mirror.

POWER: Universal power supply (AC input 100V-240V, 50/60 Hz) ISO 9001, CE approved. PACKAGING: Complete in a STYROFOAM molded box.

WARRANTY: Two Years, electrical 1 year and 3 year on optics.
