SALIENT FEATURES:-
Vacuum Pump is a gas based two-stage pump
Resistant to chemical corrosion
High corrosion resistance
Low noise, low vibration, vacuum pump motor direct power transmission driven
Overheat protection Mechanism
Pollution-free, Automatic Temperature Cool down & Stability
Noise can be maintained 70dB.
Membrane surface with PTFE coated
SPECIFICATIONS:-
|
MODEL |
LMVP20 |
|
Make |
LABMAN |
|
Power |
120 W |
|
Rotation speed |
1450 RPM |
|
Pump head type |
Two-stage |
|
Ultimate vacuum [mbar abs.] |
20 mbar |
|
Operation pressure |
1 bar (Max) |
|
Flow rate [l/min] at atm. pressure |
20 L/min |
|
Connectors for tube (mm) |
10mm |
|
Ambient Temperature |
+5oC to +40 oC |
|
Pump head Material & Diaphragm |
PTFE & PTFE coated |
|
Valves |
FKM or FFPM |
|
Power supply |
AC 220V / 50Hz |
|
Dimension (LxWxH) |
460 x 335 x 250 mm |
|
Weight |
11.2 kg |
SALIENT FEATURES:-
Vacuum Pump is a gas based two-stage pump
Resistant to chemical corrosion
High corrosion resistance
Low noise, low vibration, vacuum pump motor direct power transmission driven
Overheat protection Mechanism
Pollution-free, Automatic Temperature Cool down & Stability
Noise can be maintained 70dB.
Membrane surface with PTFE coated
SPECIFICATIONS:-
|
MODEL |
LMVP20 |
|
Make |
LABMAN |
|
Power |
120 W |
|
Rotation speed |
1450 RPM |
|
Pump head type |
Two-stage |
|
Ultimate vacuum [mbar abs.] |
20 mbar |
|
Operation pressure |
1 bar (Max) |
|
Flow rate [l/min] at atm. pressure |
20 L/min |
|
Connectors for tube (mm) |
10mm |
|
Ambient Temperature |
+5oC to +40 oC |
|
Pump head Material & Diaphragm |
PTFE & PTFE coated |
|
Valves |
FKM or FFPM |
|
Power supply |
AC 220V / 50Hz |
|
Dimension (LxWxH) |
460 x 335 x 250 mm |
|
Weight |
11.2 kg |
- Regular price
- Rs.176,950.00
- Sale price
- Rs.106,950.00
- Delivery Period :5-7 Working Days
- Replacement :3 Days Replacement as standard, Free of Cost
- Dedicated Support :Support from 9:30 AM to 6:00 PM everyday
Product Description
SALIENT FEATURES:-
Vacuum Pump is a gas based two-stage pump
Resistant to chemical corrosion
High corrosion resistance
Low noise, low vibration, vacuum pump motor direct power transmission driven
Overheat protection Mechanism
Pollution-free, Automatic Temperature Cool down & Stability
Noise can be maintained 70dB.
Membrane surface with PTFE coated
SPECIFICATIONS:-
|
MODEL |
LMVP20 |
|
Make |
LABMAN |
|
Power |
120 W |
|
Rotation speed |
1450 RPM |
|
Pump head type |
Two-stage |
|
Ultimate vacuum [mbar abs.] |
20 mbar |
|
Operation pressure |
1 bar (Max) |
|
Flow rate [l/min] at atm. pressure |
20 L/min |
|
Connectors for tube (mm) |
10mm |
|
Ambient Temperature |
+5oC to +40 oC |
|
Pump head Material & Diaphragm |
PTFE & PTFE coated |
|
Valves |
FKM or FFPM |
|
Power supply |
AC 220V / 50Hz |
|
Dimension (LxWxH) |
460 x 335 x 250 mm |
|
Weight |
11.2 kg |
