Product Description

SALIENT FEATURES:

4.3" Touch Screen Display
EMFC Technology
Multi-unit weighing function
RS232C, USB Interface
Glass windshield-antistatic material
Fast sensitivity setting
Time on display
Built-in Temperature sensor
GLP / GMP compliance

Weighing Functions
Basic weighing
Dynamic weighing
Piece counting
Percent weighing
Density determination
Ξ£ weighing function

SPECIFICATIONS:

MODEL

TAB10T

Max. ( Capacity )

81g / 220g

Readability

0.01mg / 0.1mg

Repeatability

0.01mg / 0.1mg

Linearity ( + )

0.04mg / 0.4mg

Make

WENSAR

Verification Scale Intervals (e)

1mg

Calibration

Internal Calibration

Class

Class I

Display

Touch Screen Display

Response Time

4 - 6 Sec

Pan Size (mm)

90 mm Ø

Tare Range

Full

Operating Temperature

15 C to 30 C

Sensitivity Drift (+)

2ppm / C

Density

Function Available

Data Output Mode Selection

Command & Continuous Output

Factory Reset Option

Availabe

Weighing Chamber Size

162 x 180 x 210mm

Unit

g, mg, oz, ct

Application Mode

Basic, Dynamic, Percentage Weighing, Piece Counting, Density Determination, Ξ£ weighing function

Baud rate Options

1200, 2400, 4800, 9600

Interface

RS232C, USB

Power Supply

DC9V, Adaptor using AC 220V / 50-60Hz

Dimension (LxWxH)

330 x 215 x 345 mm

Weight

9 Kg
