• MAIN BODY: Highly rigid, vibration free single piece (base, column &arm) Aluminum alloy casting, with transmitted light, power supply & brightness control integrated in the base. The frame is stable, strong, big &easy to carry. Pure white body with blue on the both sides, is fresh and vivid design.
• OPTICAL SYSTEM: Infinity color corrected optical system
• VIEWING HEAD: 30°inclined Siedentopf binocular head, interpupillary distance: 50-75mm, #5 diopter adjustable, 360° rotatable
• EYEPIECE: Wide Field plan eyepiece 10x, FOV 22mm with diopter setting
• NOSEPIECE: Inward quin tuple nosepiece with precise, positive stops for centered alignment of objectives.
• OBJECTIVE: Infinity Plan (Anti fungus. Scratch Proof) Objective  4X, 10X, 20X40X (S)and 100X Oil, (S)
• STAGE: Reckless X-Y Double Layer Mechanical rectangular stage, size 140× 132mm with cross travel 90mm (X) x65mm(Y) on ball bearing with co-axial controls.
• FOCUSING MOVEMENT: Coaxial coarse and fine adjustment, with coarse adjustment stop and tightness adjustment, range: 25mm, precision: 0.002mm..
• CONDENSER: NA. . 1.25 Abbe condenser with iris diaphragm and centrally adjustable, Pullin and Pull-out filter holder
• LIGHT SOURCE: KOHLER Illumination system LED 3.5W3V with intensity control regulator, Universal power supply 110V - 240V, CE approved.
• PACKING & ACCESORIES: Carrying Case: Styrofoam Packing &Outer corrugated box Supplied with user manual, Vinyl Dust cover, Cleaning cloth and 01 units Fuses

TECHNICAL SPECIFICATIONS:-

OPTICAL SYSTEM

Universal Infinity corrected Optical system

STAND

Stable & sturdy C shaped stand with well-contoured modular base, corrosion resistant paint and heat resistant pads. Extended base for better stability.

VIEWING HEAD

Siedentopf Binocular/Trinocular tube, inclined at 30degree rotatable through 360degree with IPD 55-75 mm. Anti fungus treated.

EYEPIECES

Focussable Eyepiece WF 10x FN 22 paired with eye guards, anti-fungus treated.

NOSEPIECE

Low friction & fully parafocal Reverse angle quadruple Revolving nosepiece (Ball bearing type) with click stop & rubber grip.
OBJECTIVES

KEOWA Plan DIN parafocal Plan Achromatic lenses, Anti fungus treated objetives:

PLAN ACHROMAT 4x/0.10

PLAN ACHROMAT 10x/0.25

PLAN ACHROMAT 40x(SL)/0.65

PLAN ACHROMAT 100x(SL, Oil)/1.25.

FOCUSING

Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways. Tension MODULE adjustment ring provided. Fine Graduation 2-3 micron.

STAGE

Ceramic coated rackless Double layer graduated mechanical rectangular stage size 140 x 132mm wire cross travel 75 (X) x 50 (Y) mm on ball bearing co-axial controls spring clip specimen holder.

CONDENSER

Movable ABBE condenser, with aspheric lens NA 1.25, daylight blue filter & Iris diaphragm. Centrable

ILLUMINATION

Koehler Illumination, Super Bright White LED cold Light, Optional 6V 20W Halogen Lamp

POWER

Universal Power Supply 100 V to 240 V,AC 50-60 Hertz, CE Compliant.

PACKAGING CONTENTS

The microscope is packed inside a STYROFOAM box with Dust Cover.

STANDARD ACCESSORIES

Styrofoam molded box, dust cover, instruction manual, and fuse.

Optional Accessories:

Upgradeable to Fluorescence attachment with battery backup.

our all products bears 2 year warranty.
