Technical Specifications:

MECHANICAL BODY: Single mold sturdy stand with anti rust materials. Extended base for better stability.

TRINOCULAR OVSERVATION HEAD: Siedentopf Trinocular 30inclined, 360rotatable. Interpupillary distance adjustable between 55-75mm. Diopter adjustment ring on ocular provides correction for eye acuity.

BUILT-IN CAMERA: Attachable camera 1/2n ccd, 2.0 mega pixel (1600x1280) with USB 2.0 PC. Output 28mm, 30mm, 34mm, and 35mm eyepiece adapter (for use with eyepiece tube).

EYEPIECE: Wide Field Eyepiece 10x (PAIRED) FOV 18mm

NOSEPIECE: Reverse angle quadruple nosepiece revolves on ball bearing with positive indexing. Soft rubber knurled grip on nosepiece.

OBJECTIVES (INFINITE):•  Plan achromatic 4x/NA 0.10 •  Plan achromatic 10x/NA 0.25 •  Plan achromatic 40x/NA 0.65 (SL) •  Plan achromatic 100x/NA 1.25 (SL) oil

MECHANICAL STAGE: Size 125x135mm, supported on ball bearing guideways and having low positioned co-axial controls for stage movement.

CONDENSER: Sub stage abbe condenser NA 1. 25 having a spherical lens, adjustable iris diaphragm and swing out filter holder. Flip type front lens condenser.

FOCUSSING: Co-axial focusing control with ball bearing guideways & large knobs, pre focusing lever & tension adjustment ring. The slow motion has 1DIV=0.002mm

ILLUMINATION: Incorporates 3W LED lamp with adjustable iris diaphragm. Power supply input from 90-240v ac with switch mode power supply. Collector in base fitted with iris diaphragm for koehler's light system.

STANDARD ACCESSORIES: Blue filter, Dust Cover, Operating Manual, STYRO FOAM Molded pack.
