Technical Specifications :

Head: Ergonomic Siedentopf Binocular head inclined at 30º rotatable at 360º. Suitable for eyepieces upto field of view 20mm. Diopter adjustment ring on ocular tube. Interpupillary distance 48-75mm adjustable. Standard ergonomically designed rugged stand for long time comfortable usage.

Eyepiece: Keowa WF 10x/FOV 18mm (PAIRED) with high point and eye guards offer maximum resolution and high colour fidelity as all of them are A.R. coated and perfectly designed for a FLAT FIELD.

Objectives: Keowa high resolution S-Plan Achromatic objectives, anti-fungus treated 4x   NA 0.10, 10x NA 0.25, 40x (Spring Loaded) NA 0.65 100x (Spring Loaded) oil immersion NA 1.25  Nosepiece: Dust proof Quadruple nosepiece revolves on ball bearing with rubber grip and positive click stop.

Mechanical Stage: Double Layer Mechanical stage size 120mm X 140mm having right sand side low positioned co-axial controls on ball bearing with fine vernier graduation. Spring clip specimen holder Cross movement travelling range : 75mm X 30mm.

Focusing: System Low position Co-axial focusing system with Tension Adjustment Ring provides a soft and sophisticated touch to the microscope.

Condenser: Focusable Abbe Condenser center able NA 1.25 with rack & pinion, aspheric lens, swing out filter holder, Iris Diaphragm with BLUE filter.

Illumination: Built-in-base transmitted illumination system 6V20W Halogen lamp or 3W LED lamp.

Power: Universal power supply (AC input 100V-240V, 50/60 Hz) ISO 9001, CE approved.

Packaging: Complete in a STYROFOAM molded box with dust cover, and -other accessories like mirror unit & power cord 1.5m in length.Warranty :  2 Years.
