Model No. CCD-5000 Make: WESWOX
0.5X REDUCTION LENS
Camera Sensor
Image Sensor: 1/1.8 Interline Sony ICX252 5 megapixel color CCD
Cooling: Peltier cooled -30degree below ambient.
Frame Rate: 5fps at 2048X1500 B/W resolutions.
Signal/Noise >72dB
Digital Output 10-bit digitization.
Software to capture and image processing.
Read Noise 12 e- rms
Power Requirement USB bus power, Operating Temperature 0 C to +60 C
Operating Humidity 5%-100%, Non-condensing
Integration Time 1/1000 sec to 12 min
Exposure time 1.6 ms to 17.8min in 1 us increament with wire port.
White Balance Automatic / Manual
Gain Programmable
Interface Connector Standard USB 2.0 high-speed interface
Product Details:
| Lens Size | 3.6 mm |
| Camera Resolution | 1 MP |
| Camera Technology | Digital Camera |
| IR Range | 10 to 15 m |
| Camera Style | WESWOX |
| Color | 100 |
| Country of Origin | Made in India |
- Regular price
- Rs.84,900.00
- Sale price
- Rs.64,400.00
Model No. CCD-5000 Make: WESWOX
0.5X REDUCTION LENS
Camera Sensor
Image Sensor: 1/1.8 Interline Sony ICX252 5 megapixel color CCD
Cooling: Peltier cooled -30degree below ambient.
Frame Rate: 5fps at 2048X1500 B/W resolutions.
Signal/Noise >72dB
Digital Output 10-bit digitization.
Software to capture and image processing.
Read Noise 12 e- rms
Power Requirement USB bus power, Operating Temperature 0 C to +60 C
Operating Humidity 5%-100%, Non-condensing
Integration Time 1/1000 sec to 12 min
Exposure time 1.6 ms to 17.8min in 1 us increament with wire port.
White Balance Automatic / Manual
Gain Programmable
Interface Connector Standard USB 2.0 high-speed interface
Product Details:
| Lens Size | 3.6 mm |
| Camera Resolution | 1 MP |
| Camera Technology | Digital Camera |
| IR Range | 10 to 15 m |
| Camera Style | WESWOX |
| Color | 100 |
| Country of Origin | Made in India |
- Regular price
- Rs.84,900.00
- Sale price
- Rs.64,400.00
- Delivery Period :5-7 Working Days
- Replacement :3 Days Replacement as standard, Free of Cost
- Dedicated Support :Support from 9:30 AM to 6:00 PM everyday
