Technical Specifications :

OPTICAL SYSTEM: Infinity corrected optical system

BINOCULAR OBSERVATION HEAD: Siedentopf Binocular head inclined at 30o rotatable at 3600. Suitable for eyepieces upto field of view 20mm. Diopter adjustment ring on ocular tube.Interpupillary distance 48-75mm adjustable.Standard ergonomically designed rugged stand for long time comfortable usage.

CAMERA : Image Sensor : ½” CMOS 5.0MP, Resolution : 2592 X 1944 (5.17M Pixels), Frame Rate : 7.5 fps, 1280X960, 2.5 frames/sec, @ 2592 X 1944, Output Interface : USB-2.0/3.0, Software : Preview, static capture, video capture.System Required : Microsoft windows 2000, XP SP2/SP3, Vista;USB2.0 Port, Application : High resolution microscope imaging, Mount : C/CS mount. Mounting Tube : 23mm, Camera size : 60mm diameter, Image File Type  : JPEG, PNG, BMP, TIF.

EYEPIECE: KEOWA WF 10x/FOV 18mm (PAIRED) with high point and eyeguards offer maximum resolution and high colour fidelity as all of them are A.R. coated and perfectly designed for a FLAT FIELD.

OBJECTIVES: KEOWA high resolution Infinity S-Plan DIN Achromatic objectives, anti-fungus treated 4x NA 0.10, 10x NA 0.25, 40x (Spring Loaded) NA 0.65, 100x (Spring Loaded) oil immersion NA  1.25.

NOSEPIECE: Dust proof Quadruple nosepiece revolves on ball bearing with rubber grip and positive click stop.

MECHANICAL STAGE: Double Layer Mechanical stage size 120mm X 140mm having right sand side low positioned co-axial controls on ball bearing with fine vernier graduation. Spring clip specimen holderCross movement travelling range  :75mm X 30mm.

FOCUSSING SYSTEM: Low position Co-axial focusing system with TENSION ADJUSTMENT RING provides a soft and sophisticated touch to the microscope.

SUB STAGE CONDENSER: Focusable Abbe Condenser centerable NA 1.25 with rack & pinion, aspheric lens, swing out filter holder, Iris Diaphragm with BLUE filter.

ILLUMINATION: Built-in-base transmitted illumination system 6V20W Halogen lamp or 3W LED lamp.

POWER: Universal power supply (AC input 100V-240V, 50/60 Hz) ISO 9001, CE approved.
