Technical Specifications :

OPTICAL SYSTEM : Universal Infinity corrected Optical system

STAND  : Stable & sturdy C shaped stand with well-contoured modular base, corrosion resistant paint and heat resistant pads. Extended base for better stability.

VIEWING HEAD: Siedentopf Binocular/Trinocular tube, inclined at 30° rotatable through 360° with IPD 55-75 mm. Anti fungus treated.

LCD DIGITAL CAMERA: Display 8" High-resolution(1024x768) Color LCD Touch ScreenBuilt-in Camera 5.0 Megapixel Color Camera 15fps 2592X1944.Built-in Software Capture/Measurement App Mechanical Structure LCD Screen 360° horizontal rotatable, 90° vertical rotatable Operating System Android. Output Ports 1 HDMI Port.  1 USB 2.0 Port,  1 Mini USB 2.0 PortPower Supply Input   : AC 110V-220V  Output : DC 5V   Features :  Browser, Calender, Camera, Chrome, Clock, Downloads, Thousand of Applications Capture Image  -  Frame Rate - Managing and Browsing Images -Measuring Toolbars

EYEPIECES: Focussable Eyepiece WF 10x FN 22 paired with eye guards, anti-fungus treated. NOSEPIECE:  Low friction & fully parafocal Reverse angle quintuple Revolving nosepiece (Ball bearing type) with click stop & rubber grip.

OBJECTIVES: KEOWABJ series All New High Definition Infinity Plan DIN parafocal Plan Achromaticlenses, Anti fungus anti mold  treated  objetives: PLAN ACHROMAT 4x/0.10 PLAN ACHROMAT 10x/0.25PLAN ACHROMAT 40x(SL)/0.65PLAN ACHROMAT 100x(SL, Oil)/1.25.

FOCUSING:  Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways.  Torque MODULE adjustment ring provided. Fine Graduation 2.5micron. Coarse movement stroke 20mm.

STAGE:  Rackless Double layer graduated mechanical rectangular stage size 220 x 150mm wire cross travel 75 (X) x 50 (Y) mm on ball bearing co-axial controls spring clip specimen holder. Focus lock for mechanical stage provided.

CONDENSER: Movable ABBE condenser, with aspheric lens NA 1.25, daylight blue filter & Iris diaphragm. Centrable. Compatible with 4x-100x,

ILLUMINATION: Koehler Illumination, Super Bright White LED cold Light or 6V 20W Halogen Lamp. SMPS circuit for constant voltage output.

POWER:  Universal Power Supply 100 V to 240 V,AC 50-60 Hertz, CE Compliant.

PACKAGING: The microscope is packed inside a STYROFOAM box with Dust Cover.

CONTENTS:

STANDARD: Styrofoam molded box, dust cover, instruction manual, fuse, ,spare.®
