Technical Specifications :

BASE: Single mold sturdy stand with anti rust materials and extended base.

BINOCULAR OBSERVATION HEAD: Trinocular Observation head inclined at 45o rotatable at 360º.

CAMERA: Image Sensor  : ½.5” CMOS 3.0MP, Resolution : 2048 X 1536 (3.0M Pixels), Frame Rate : 3fps@2048x1536; 30 fps@640 ×480, Output Interface : USB-2.0/3.0, Software : Preview, static capture, video capture. System Required : Microsoft windows 2000, XP SP2/SP3, Vista;USB2.0 Port, Application : High resolution microscope imaging, Mount : C/CS mount. Mounting Tube : 23mm, Camera size : 60mm diameter, Image File Type  : JPEG, PNG, BMP, TIF.

 EYEPIECE: KEOWA WIDE FIELD HKW10x paired with eye guards.

OBJECTIVES: KEOWA Semi Plan Achromatic Objectives, anti-fungus treated 4x/NA0.10, 10x/NA0.25, 40x/NA0.65 (Spring Loaded), 100x/NA1.25 (SL, oil immersion)

NOSEPIECE: Quadruple nosepiece revolves on ball bearing with rubber grip and positive click stop.

MECHANICAL STAGE: Right Hand Mechanical stage size 120mm X 140mm having low positioned co-axial controls on ball bearing. Spring clip single specimen holder Cross X&Y movement 60mm X 80mm.

FOCUSSING SYSTEM: Low position Co-axial graduated coarse & fine focusing system with TENSION ADJUSTMENTRING provides a soft and sophisticated touch to the microscope. Coarse Movement stroke : 20mm tension on the right.

SUBSTAGE CONDENSER: Focusable Abbe Condenser centerable NA1.25 with aspheric lens, filter holder, Iris Diaphragm movable on rack & pinion with BLUE filter. Vertical adjustment range: 10mm.

ILLUMINATION: Built-in-base illumination system with 6V 20W Halogen lamp or 3W LED lamp with intensity controlled power supply & day light reflector/mirror.

POWER: Universal power supply (AC input 100V-240V, 50/60 Hz) ISO9001, CE approved.

PACKAGING: Complete in a STYROFOAM molded box.
