Technical Specifications :

OBSERVATION HEAD: inclined at 45o rotatable at 360º.Diopter adjustment ring on ocular tube. Interpupillary distance adjustable 55-75mm.

LCD CAMERA: 3.5 inch LCD screen with 2MP camera, USB port, image analysis & measurement software.

EYE PIECE: KEOWA WIDE FIELD 10x/FOV 18mm (PAIRED) with high point and eye guards.

OBJECTIVE: KEOWA MJ Series Semi-Plan Achromatic Objectives, anti-fungus treated 4x, 10x, 40x (S L), 100x (S L) oil immersion.

NOSEPIECE: Dust proof Quadruple nosepiece revolves on ball bearing with rubber grip and positive click stop.

STAGE: Double layer Mechanical stage size 120mm X 140mm having low positioned co-axial controls on ball bearing with fine vernier graduation. Cross movement 60mm X 80mm.

FOCUSING: Low position Co-axial focusing system with TENSION ADJUSTMENT RING on right side Focusable Abbe Condenser centerable NA 1.25 with rack & pinion, aspheric lens, swing out filter holder, Iris Diaphragm with BLUE filter.

ILLUMINATION: Built-in-base illumination system with 6V 20W bulb with intensity controlled unit.

SUPPLY: Universal power supply (AC input 100V-240V, 50/60 Hz) ISO 9001, CE approved.

PACKING: Complete in a STYROFOAM molded box with dust cover, and other accessories.

WARRANTY: Two years
