MODELS & SPECIFICATIONS

Model: LMDF-86V108

• External Size (W×D×H) mm: 700 × 730 × 1260

• Internal Size (W×D×H) mm: 460 × 460 × 510

• Capacity: 108L

• Type: Vertical

• Temperature Range: -40°C ~ -86°C

• Temperature Accuracy: 0.1°C

• Control System: Microprocessor control, LED display

• Audio & Visual Alarm: High and low temperature, Sensor failure

• Refrigeration Type: Direct refrigeration

• Refrigerant: Mixture refrigerant

• Compressor: 1 set

• Condenser & Evaporator: Made of copper

• Structure: Unibody design & Mono-assembly foaming (Rigid polyurethane insulation material)

• Construction:

  • Internal Material: SS 304

  • External Material: Cold-rolled steel with anti-bacteria powder coating

• Door: Lockable door

• Caster: 4 casters

• Chamber with Inner Door: 2

• Temp. Test Port: 1, φ20mm

• Consumption: 450W

• Power Supply: AC110V/220V ±10%, 50/60Hz

• Standard Accessory: USB port

• Optional Storage Racks: No

• Accessory (Boxes): No

• Package Size (W×D×H) mm: 785 × 800 × 1430

• Gross Weight: 133kg

Model: LMDF-86V340

• External Size (W×D×H) mm: 854 × 1006 × 1907

• Internal Size (W×D×H) mm: 488 × 607 × 1140

• Capacity: 340L

• Type: Vertical

• Temperature Range: -40°C ~ -86°C

• Temperature Accuracy: 0.1°C

• Control System: Microprocessor control, LED touch screen

• Audio & Visual Alarm:
  High and low temperature, Sensor failure, Door ajar, Power failure, Voltage abnormal, Ambient temperature abnormal, Low voltage, Filter blocking

• Refrigeration Type: Direct refrigeration

• Refrigerant: Mixture refrigerant

• Compressor: 2 sets

• Condenser & Evaporator: Made of copper

• Structure: Unibody design & Mono-assembly foaming (Rigid polyurethane insulation material)

• Construction:

  • Internal Material: SS 304

  • External Material: Cold-rolled steel with anti-bacteria powder coating

• Door: Lockable door

• Caster: 4 casters

• Chamber with Inner Door: 2

• Temp. Test Port: 1, φ23mm

• Consumption: 810W

• Power Supply: AC220V ±10%, 50/60Hz

• Standard Accessory: USB port

• Optional Storage Racks: 12 racks (4×4)

• Accessory (Boxes): 192 boxes

• Package Size (W×D×H) mm: 935 × 1070 × 2130

• Gross Weight: 283.5kg

Model: LMDF-86V588

• External Size (W×D×H) mm: 891 × 1155 × 1994.5

• Internal Size (W×D×H) mm: 606 × 738 × 1310

• Capacity: 588L

• Type: Vertical

• Temperature Range: -40°C ~ -86°C

• Temperature Accuracy: 0.1°C

• Control System: Microprocessor control, LCD touch screen

• Compressor: 2 sets

• Structure: Unibody design & Mono-assembly foaming (Rigid polyurethane insulation material)

• Construction:

  • Internal Material: SS 304

  • External Material: Cold-rolled steel with anti-bacteria powder coating

• Chamber with Inner Door: 2

• Temp. Test Port: 1, φ25mm

• Consumption: 815W

• Power Supply: AC110V/220V ±10%, 50/60Hz

• Storage Racks: 16 racks (5×5)

• Boxes: 400 boxes

• Package Size (W×D×H) mm: 975 × 1140 × 2200

• Gross Weight: 368kg

Additional Available Models

• LM-ULT-300L

• LM-ULT-400L

• LM-ULT-500L

• LM-ULT-600L

• LM-ULT-700L

• LM-ULT-800L

• LM-ULT-900L

• LM-ULT-1000L

Capacity Ranges:
200–300L | 301–400L | 401–500L | 501–600L | 601–700L | 701–800L | 801–900L | 901–1000L

Dimensions available on demand due to customized item.

Applications

• Hospitals

• Blood Banks

• Research Institutions

• Universities

• Biological Pharmacies

• Genetic Engineering Labs
